Ubiquiti IsoStation M5 – IS-M5

Ubiquiti IsoStation M5

The Ubiquiti IsoStation M5 provides high isolation solutions in fixed beamwidth increments through interchangeable horn antennas that have been optimized for an urban environment.

Ubiquiti IsoStation M5 Features

• Throughput 100+ Mbps
• Interchangeable Isolation Antenna Horn
• All-Metal, Shielded Radio Base
• airMAX Processor for Superior Performance

The tailored antenna radiation patterns spatially filters bothin-band and out-of-band spurious RF emissions to increase the noise immunity of the IsoStation M5. This feature is especially important in an increasingly congested RF environment.

Modular Design
With flexible sectorization for optional antenna beamwidths, thehorn antenna is interchangeable and improves beam‑shaping for specific deployment and environment needs.The IsoStation M5 uses horn antenna sectors designed for increasedco-location performance without sacrificing gain. Providing high throughput and an innovative form factor, the IsoStation M5 is versatile and cost‑effective to deploy.

Symmetrical Antennas
Symmetrical horn antennas (30° and45° versions) offer breakthrough scalability options for wireless systems. They are ideal for cluster sector installations with highco‑location requirements. Unique beam performance and greatco-location characteristics allow for a higher density of sectors than traditional sector technology.

Enhanced Co-Location
Asymmetrical horn antenna options (60° and 90°) have naturally attenuated side lobes and extremely low back radiation, and they offer industry-leading front-to-back ratio and low side lobe radiation. Symmetrical horn antennas (30° and 45°, the default) are ideal for cluster sector installations with high co-location requirements.

Ubiquiti IsoStation, 5GHz airMAX CPE Radio with speeds up to 100+Mbps, 14dBi interchangeable Isolation Antenna; all-metal shielded radio base; 5+km range; v5.6.x airOS with airMAX processor.

Model:

IS-M5

ISM5
